Product Specifications
Dimensions
Length: 12,240 mm
Width: 2,550 mm
Height: 3,640 mm
Width: 2,550 mm
Height: 3,640 mm
Max. Payload & Weight
50,000 Liter
11,600 kg - Approximately
Tank
Length: 11,830 mm / Dia.: 2,400 mm / Wall Thickness: 10 mm (P460NL2)
End Cap Thickness: 12 mm (P355NL2)
End Cap Thickness: 12 mm (P355NL2)
Valves
2 x Safety valves 3" / 1 x Filler Valve 3" / 2 x Valves 3" / 1 x Valve 2"
1 x Excess flow valve 2" / 1 x Check Valve 3"
1 x Thermometer / 1 x Pressure Gauge / 1 x Rotogage Assembly 1"
1 x Excess flow valve 2" / 1 x Check Valve 3"
1 x Thermometer / 1 x Pressure Gauge / 1 x Rotogage Assembly 1"
Work Conditions & Standards
Design standard: EN 12493-2008
Testing standard: EN 12493-2008 & ISIRI 841
Test pressure: 375 psi
Working pressure: 250 psi
Working temp: -40 °C to +50 °C
Testing standard: EN 12493-2008 & ISIRI 841
Test pressure: 375 psi
Working pressure: 250 psi
Working temp: -40 °C to +50 °C
Chassis
Rear semi-chassis & components from St 52-3 / QST 380 / S 500 / Automatic CO2 welding technology / Merkle, Germany / Main beams with standard flat bar / All steel stamping parts are assembled using special fixture
Axle & Suspension
3 x 9 tons SAF® / BPW® / MAMMUT®
Front axle with automatic lifting capability
Air suspension with special shock absorbers
Automatic lowering and rising of trailer height
Front axle with automatic lifting capability
Air suspension with special shock absorbers
Automatic lowering and rising of trailer height
Tire/Rim
6 x Radial tires 385/65/R22.5
6 x Single rims 11.75 x R22.5"
6 x Single rims 11.75 x R22.5"
Landing Gear
Two mechanically operated landing legs 24 tons dynamic capacity & 50 tons static capacity
Operated from right side.
King Pin
2" dia. (162 KN) with coupling according to SAE standard with special bolster plate according to UNECE regulation ECE-R55 standard.
Corner dimension: 2040 mm
Corner dimension: 2040 mm
Braking System
Knorr, WABCO 2S/2M, Disk/Drum according to ECE-R13 standard.
Dual circuit pneumatic with automatic load sensing valves
Two double acting diaphragm brake chambers (2 rear axles)
EBS incl. ABS & RSP (Roll Stability Program)
Emergency valve / Parking brake / Reset-to-Ride height function.
Dual circuit pneumatic with automatic load sensing valves
Two double acting diaphragm brake chambers (2 rear axles)
EBS incl. ABS & RSP (Roll Stability Program)
Emergency valve / Parking brake / Reset-to-Ride height function.
Electrical System
7 & 15 Poles quick release connector with 24 volts rear and side lights plus LED alarming system
According to UNECE regulation R48
Painting
Shot blasted according to SA 2.5 / Epoxy sub-coat / Final polyurethane coating as per customer requirement / Color According to RAL system
Accessories
Rear guard protection / Rear under-run protection according to UNECE Regulation ECE-R73
6 x Semi-circle mud guards
2 x Rear Spray suppression system according to UNECE Regulation-EU 109/2011
2 x Wheel chocks with holders
1 x Fire extinguisher holder in rear
Spare wheel carrier with clamp mechanism
1 x Tool box (1.22 m) Operated in rear
Side protection and Reflective Ribbon outline marking on side/rear according to UNECE Regulation
6 x Semi-circle mud guards
2 x Rear Spray suppression system according to UNECE Regulation-EU 109/2011
2 x Wheel chocks with holders
1 x Fire extinguisher holder in rear
Spare wheel carrier with clamp mechanism
1 x Tool box (1.22 m) Operated in rear
Side protection and Reflective Ribbon outline marking on side/rear according to UNECE Regulation
Options
125 L stainless steel water tank / Spare tire & rim / Tire-pressure monitoring system (TPMS)
Licenses
Certified by INSO (Iran National Standards Organization) & Type approval of vehicles - European Commission
The Intersection of Quality & Innovation
Product Details
To purchase Mammut World LPG Tanker Semi-trailer, simply get in touch with us!
If you are looking for information on the price of Mammut World LPG Tanker Semi-trailer, renowned for its excellent quality and outstanding performance in transporting temperature-sensitive goods—simply contact us! For detailed information, pricing, and expert consultation, reach out now at +98 0264500 or +98 0214500. Our specialists are ready to provide you with the best purchasing experience.
Discover More About the Mammut LPG Tanker Semi-trailer!
What Is the Mammut LPG Tanker Trailer Designed For?
This tanker trailer is specifically designed for transporting liquefied petroleum gas (LPG) and is used across various energy industries and fuel distribution sectors.
What Is the Tank Capacity of a Mammut LPG Tanker Semi-Trailer?
The capacity varies depending on the model and customer specifications, but it is typically designed to hold between 40,000 and 60,000 liters.
What Material Is the Tank of a Mammut LPG Tanker Semi-Trailer Made Of?
The tanks are made of high-quality steel that is resistant to pressure and corrosion, ensuring both safety and long service life.
What Safety Systems Are Installed on a Mammut LPG Tanker Semi-Trailer?
These tanker semi-trailers are equipped with safety valves, pressure control systems, safety vents, and corrosion-resistant coatings.
Does the Mammut LPG Tanker Semi-Trailer Comply with International Standards?
Yes, all Mammut products are designed and tested in accordance with both national and international standards.
Is It Possible to Customize a Mammut LPG Tanker Semi-Trailer?
Yes, customers can choose the capacity, type of safety equipment, and even the exterior design according to their specific requirements.
What Is the Empty Weight of a Mammut LPG Tanker Semi-Trailer?
The empty weight varies depending on the model, but it is generally considered to be between 12 and 14 tons.
Does Driving a Mammut LPG Tanker Semi-Trailer Require Special Training?
Yes, drivers must complete hazardous materials (ADR) training and be familiar with safety procedures for transporting LPG.
What Advantages Does the Mammut LPG Tanker Semi-Trailer Have Compared to Similar Models?
High strength, long durability, compliance with environmental standards, and extensive after-sales support are the main advantages of this product.
Are After-Sales Services and Spare Parts Available for the Mammut LPG Tanker Semi-Trailer?
Yes, Mammut provides customers with an extensive network for after-sales services and spare parts supply.
