Curtainsider Semi-trailer

Question 1

Dimensions

Answer

Length: 13,740 mm (inside 13,640)
Width: 2,580 mm (inside 2,480)
Height: 4,100 mm (Load height 2,750)

Question 2

Max. Payload & Weight

Answer

Fixed Curtainsider Semi-trailer
26,000 kg (93 cubic meter)
Ability to carry 34 standard pallets
7,100 kg – Approximately

Sliding Curtainsider Semi-trailer
26,000 kg (93 cubic meter)
Ability to carry 34 standard pallets
7,400 kg – Approximately

Question 3

Body

Answer

Front wall from Aluminum profile
Steel integrated corner pillars
Steel side posts as sliding mechanism and positioned opposite each other symmetrically
Drop side doors (4 or 5) from special Aluminum profile
Plank pockets for AL stanchions
Flooring from 28 mm water resistant anti scratch plywood

Question 4

Curtain

Answer

Special polymer with high temperature resistance (from -30˚c to +70˚c)
Tear resistant / incl. Reinforcing strips / High color stability /High tensile strength/Welding adhesion

Question 5

Rear Doors

Answer

Special Aluminum profile with steel pillars
8 x Aluminum hinges, 2 x Galvanized locks and Special sealing rubber

Question 6

Chassis

Answer

Chassis & components from St. 52-3 / QST 380 / S 500
Automatic CO2 welding technology / Merkle, Germany
Main beams with standard flat bar
All steel stamping parts are assembled using special fixture
and automatic devices

Question 7

Axle & Suspension

Answer

3 × 9 tons SAF® / BPW® / MAMMUT®
Front axle with automatic lifting capability
Air suspension with special shock absorbers Lowering and rising of trailer heigh

Question 8

Sliding Mechanism

Answer

Independently sliding movement of roof and side wall
Galvanized, movable, and removable roof tent support poles, movable roof carriage on two continuous and specialized aluminum rails
Has specialized tent straps with hooks

Question 9

Tire/Rim

Answer

6 × Radial tires 385/65 R22.5
6 × Single rims 11.75 × R22.5²

Question 10

Landing Gear

Answer

Two mechanically operated landing legs 24 tons dynamic capacity & 50 tons static capacity
Operated from right side

Question 11

King Pin

Answer

2” dia. (162 KN) with coupling
according to SAE standard with special bolster plate
Corner dimension :2040 mm

Question 12

Braking System

Answer

Knorr , WABCO, HALDEX 2S/2M Germany, Disk/Drum according to ECE-R13 standard.
Dual circuit pneumatic with automatic load sensing valves
Dual circuit pneumatic with automatic load sensing valves
Two double acting diaphragm brake chambers (2 rear axles)
EBS incl. ABS & RSP (Roll Stability Program) / Emergency valve / Parking brake/Reset-to-Ride height function.

Question 13

Electrical System

Answer

7 & 15 Poles quick release connector with 24 volts rear and side lights plus LED alarming system According to UNECE regulation R48. R48

Question 14

Painting

Answer

Shot blast preparation process according to SA2.5 standard
Cationic phosphate
ED with a thickness of 20 microns
Powder color of 80 microns or polyurethane with a thickness of 100 microns
Color RAL according to customer

Question 15

Accessories

Answer

Rear guard protection / Rear under-run protection according to UNECE Regulation ECE-R73
2 × Rubber buffer absorbers (rear) / 2 × Carrier hooks
6 × Semi-circle mudguards
1 × Rear suppression system according to UNECE Regulation-EU 109/2011
2 × Wheel chocks and holders / Fire extinguishing bracket
Spare wheel carrier with coupling mechanism
2 × Tool boxes (2.5 m) with two different models
Load lashing belts / 3-Step Ladder Under Platform / Aluminum ladder
Rear door rubber buffer shock absorbers
Rear door stopper / Side protection and Reflective Ribbon outline marking on side/rear according to UNECE Regulation

Question 16

Options

Answer

125 L stainless steel water tank / Spare tire & rim
Tire-pressure monitoring system (TPMS)

Question 17

Customized Models

Answer

Fixed 4-door Curtainsider Semi-trailer
Fixed 5-door Curtainsider Semi-trailer
Sliding 4-door Curtainsider Semi-trailer
Sliding 5-door Curtainsider Semi-trailer
Coil Carrier Curtainsider Semi-trailer
Quick Opening Curtainsider Semi-trailer

Question 18

Licenses

Answer

Certified by INSO (Iran National Standards Organization) & Type approval of vehicles – European Commission

Question 19

What is a Curtain-Side Semi-Trailer and What Are Its Applications?

Answer

A curtain-side semi-trailer is a type of semi-trailer covered with durable fabric (tarpaulin) and is ideal for transporting goods that require protection from weather conditions, such as industrial products, packaged materials, and non-temperature-sensitive cargo.

Question 20

Is the Mammut Curtain-Side Semi-Trailer Waterproof?

Answer

Yes, the tarpaulin cover of curtain-side semi-trailers is generally waterproof, protecting goods from rain and moisture. However, in extreme weather conditions, such as storms, additional reinforcement of the cover may be necessary.

Question 21

What is the Load Capacity of a Mammut Curtain-Side Semi-Trailer?

Answer

The load capacity of a Mammut curtain-side semi-trailer varies depending on its model and construction, but it typically can carry between 10 to 20 tons of cargo.

Question 22

Is the Mammut Curtain-Side Semi-Trailer Suitable for Transporting Large and Bulky Loads?

Answer

Yes, the Mammut curtain-side semi-trailer can be used to transport large and bulky loads, especially when the cargo requires protective coverage and needs to be shielded from weather conditions.

Question 23

Is the Curtain-Side Semi-Trailer Suitable for Transporting Perishable Goods?

Answer

No, curtain-side semi-trailers are not suitable for transporting perishable goods because they lack thermal insulation and refrigeration systems. For such cargo, a refrigerated trailer is a better option, as it allows temperature control and prevents spoilage. However, for short distances in mild weather, with proper packaging and quick transport, a curtain-side semi-trailer can be used.

Question 24

Is It Possible to Quickly Open and Close the Tarpaulin Cover of a Mammut Curtain-Side Semi-Trailer?

Answer

Yes, curtain-side semi-trailers are designed so that their tarpaulin covers can be easily opened and closed, enabling fast loading and unloading of cargo.

Question 25

How Can I Ensure the Strength and Durability of a Curtain-Side Semi-Trailer’s Tarpaulin Cover?

Answer

Mammut curtain-side semi-trailers are typically made from tarpaulin materials that are resistant to tension, tearing, and various weather conditions. You can request detailed information about the fabric type and the durability tests it has undergone.

Question 26

Is the Mammut Curtain-Side Semi-Trailer Suitable for Long-Distance Transport?

Answer

Yes, the Mammut curtain-side semi-trailer is suitable for transporting goods over long distances due to its lightweight design, high load capacity, and side and rear loading options. It is ideal for packaged goods, industrial items, and commercial cargo. However, for weather-sensitive or perishable goods, alternatives such as refrigerated or container semi-trailers are recommended.

Question 27

Is It Possible to Order a Curtain-Side Semi-Trailer with Custom Dimensions?

Answer

Yes, you can order a Mammut curtain-side semi-trailer with custom dimensions for cargo of specific sizes. This customization is usually handled by our team based on customer requirements; simply contact us at 0264500 for consultation.
