Product Specifications
Dimensions
Length: 9,850 mm
Width: 2,550 mm
Height: 4,000 mm
Width: 2,550 mm
Height: 4,000 mm
Max. Payload & Weight
Max. Payload: 28 m3
Weight: 7,700 kg (w/o motor) - Approximately
Weight: 7,700 kg (w/o motor) - Approximately
Tank
Steel plate 4 mm St. 37 / Special anti slip checkered steel passage on top with fixed guard
Shell, end-caps and baffles are leak-proof welded continuously using automatic welding machine
Welding quality control
Valves and Piping
Piping: compressed air (2" line) / cement draining (4" line)
1 x sliding valve 4" in bottom of the tank
2" valves, check valves and gauges in the path from compressor to the tank
1 x sliding valve 4" in bottom of the tank
2" valves, check valves and gauges in the path from compressor to the tank
Chassis
Chassis & components from St. 52-3 / QST 380 / S 500 / Automatic CO2 welding technology / Merkle, Germany
Main beams with standard flat bar / All steel stamping parts are assembled using special fixture
Axle & Suspension
3 x 9 tons SAF® / BPW® / MAMMUT®
Front axle with automatic lifting capability
Air suspension with special shock absorbers / Lowering and rising of trailer height
Front axle with automatic lifting capability
Air suspension with special shock absorbers / Lowering and rising of trailer height
Tire/Rim
6 x Radial tires 385/65/R22.5 / 6 x Single rims 11.75 x R22.5"
Landing Gear
Two mechanically operated landing legs 24 tons dynamic capacity & 50 tons static capacity
Operated from right side
King Pin
2" dia. (162 KN) with coupling according to SAE standard with special bolster plate
according to UNECE regulation ECE-R55 standard.
Corner dimension: 2040 mm
Corner dimension: 2040 mm
Brake System
Knorr, WABCO 2S/2M Disk/Drum according to ECE-R13 standard.
Dual circuit pneumatic with automatic load sensing valves
Two double acting diaphragm brake chambers (2 rear axles)
EBS incl. ABS & RSP (Roll Stability Program)
Emergency valve / Parking brake / Reset-to-Ride height function
Dual circuit pneumatic with automatic load sensing valves
Two double acting diaphragm brake chambers (2 rear axles)
EBS incl. ABS & RSP (Roll Stability Program)
Emergency valve / Parking brake / Reset-to-Ride height function
Electrical System
7 & 15 Poles quick release connector with 24 volts rear and side lights plus LED alarming system
According to UNECE regulation R48
Painting
Shot blasted according to SA 2.5 / Epoxy sub-coat
Final polyurethane coating as per customer requirement / Color According to RAL system
Final polyurethane coating as per customer requirement / Color According to RAL system
Accessories
Rear guard protection / Rear under-run protection according to UNECE Regulation ECE-R73
6 x Semi-circle mud guards
2 x Spray suppression system according to UNECE Regulation-EU 109/2011
2 x Wheel chocks and holders
Fire extinguisher bracket
Spare wheel carrier with clamp mechanism
Rear steel ladder
3 x hatches on the tank
Side protection and Reflective ribbon outline marking on side/rear according to UNECE Regulation
6 x Semi-circle mud guards
2 x Spray suppression system according to UNECE Regulation-EU 109/2011
2 x Wheel chocks and holders
Fire extinguisher bracket
Spare wheel carrier with clamp mechanism
Rear steel ladder
3 x hatches on the tank
Side protection and Reflective ribbon outline marking on side/rear according to UNECE Regulation
Options
Water tank - 56 L
Spare tire & rim
Tire-pressure monitoring system (TPMS)
1 x Compressor plus 1 x Diesel generator with draining capacity of 1 ton/min
Spare tire & rim
Tire-pressure monitoring system (TPMS)
1 x Compressor plus 1 x Diesel generator with draining capacity of 1 ton/min
Licenses
Certified by INSO (Iran National Standards Organization) & Type approval of vehicles - European Commission
The Intersection of Quality & Innovation
Product Details
To purchase Mammut World Bulker Semi-trailer, simply get in touch with us!
If you are looking for information on the price of Mammut World Bunker Semi-trailer, renowned for its excellent quality and outstanding performance in transporting temperature-sensitive goods—simply contact us! For detailed information, pricing, and expert consultation, reach out now at +98 0264500 or +98 0214500. Our specialists are ready to provide you with the best purchasing experience.
Discover More About the Mammut Bulker Semi-Trailer!
What is a Bulker Semi-Trailer and What is it Used For?
A bulker semi-trailer is a specialized trailer designed for transporting dry bulk materials such as cement, lime powder, or minerals. Its tank-like design enables the safe and cost-effective transport of large volumes of materials.
What is the Load Capacity of a Bulker Semi-Trailer?
The carrying capacity of a bulker semi-trailer varies depending on its design and manufacturer. However, standard models typically offer up to 28 cubic meters of storage, making them highly suitable for large-scale construction projects.
What is the Difference Between a Bulker Semi-Trailer and Other Types of Trailers?
Unlike flatbed or tipper semi-trailers, a bulker semi-trailer features a closed tank specifically designed for transporting powdered materials. Its loading and unloading processes are mechanized, allowing for faster and more efficient handling.
Does a BunkerBulker Semi-Trailer Require a Special Permit for Registration?
Yes, a bulker semi-trailer must have a registration permit from the National Standards Organization of Iran to operate legally on the roads. Mammut bulker semi-trailers are fully certified with this permit.
How Does a Bulker Semi-Trailer Unload Its Cargo?
A bulker semi-trailer unloads its cargo using a sloped design and an air-assisted discharge system, allowing materials to flow out quickly and evenly. In advanced models, a 1.5-degree slope is incorporated to facilitate even easier unloading.
What Safety Features Does a Bulker Semi-Trailer Include?
Advanced bulker semi-trailers, such as those from Mammut World, are equipped with an Electronic Braking System (EBS) and a Roll Stability Program (RSP), ensuring the safety of both the cargo and the driver under various road conditions.
Is a Bulker Semi-Trailer Suitable for Transporting Materials Other Than Cement?
Yes, a bulker semi-trailer can transport dry bulk materials such as lime powder, gypsum, and certain minerals. However, it is important to ensure that the type of material is compatible with the trailer’s tank design standards.
How is the Maintenance and Periodic Servicing of a Bulker Semi-Trailer Performed?
A bunker semi-trailer should be regularly inspected for its compressed air system, loading hatches, valves, and chassis. Proper maintenance increases its service life and helps reduce repair costs.
What Features Make the Mammut Bulker Semi-Trailer Stand Out Compared to Competitors?
The Mammut bulker semi-trailer, featuring optimized design, a robust chassis, high-quality materials, and full compliance with national standards, is a professional and reliable choice for transporting bulk materials.
What Factors Affect the Price of a Bulker Semi-Trailer?
The price of a bulker semi-trailer depends on factors such as tank capacity, chassis type, safety equipment, manufacturer brand, and after-sales services. To obtain the price of a Mammut bulker semi-trailer, simply contact an authorized dealer.
